SYD系列型液压打包机主要用于将布匹、棉花纤、废棉、羊毛、毛球等纺织原料及制品压缩后打包，以便于储存和运输，亦适用于类似松散物料的打包之用。

主要技术参数
1、公称压力分为：400KN、630KN、750KN、120KN、150KN
2、工作行程：1200mm
3、压板下行速度：＞65mm/s
4、压板上行速度：＞130mm/s
5、工作台面尺寸：1300*680mm  （特殊规格商订）
6、液压系统工作压力：25Mpa
7、液压用油：20#或32#液压油
8、装机功率：5.5KW、7.5KW、11KW、15KW
9、外形尺寸：2500*900*3600mm
10、全机重量：2400Kg

Ⅰ. Purpose
SYD series hydraulic packaging machine is mainly used for baling cloth, cotton fiber, waste cotton, wool, fur cones and other textile raw materials and products after being compressed for convenient storage and transportation. It also can be applied to the baling of similar loose materials.
Ⅱ. Main technical parameter
1. Nominal pressure can be divided into: 400KN, 630KN, 750KN, 120KN, 150KN
2. Working stroke: 1200mm
3. Clamp down speed: ≥65mm/s
4. Clamp upstream speed: ＞130mm/s
5. Size of worktable: 1300x 680mm (Special specification should be ordered after negotiated)
6. Hydraulic system working pressure: 25Mpa
7. Hydraulic oil: 20# or 32# hydraulic oil
8. Installed power：5.5kw, 7.5kw, 11kw, 15kw
9. Overall dimension: 2500 x 900 x 3600mm
10. Machine weight: 2400kg
