YG086C缕纱测长仪

YG086C型缕纱测长仪
Model YG086C Measuring Reel Tester
　　用于将纱线管上试样纱线用纱框摇取缕纱，供纱线的线密度(或支数)的测定及缕纱
　　强度试验等用。性能符合GB/T4743-1995《纱线线密度的测定 绞纱法》。
　　Used to rock skein by reel from sample yarn in bobbin for measurement of linear
　　density (or count) and test of skein strength. The properties shoukd be in conformity
　　with the requirement specified in GB/T4743-1995 "Determination of yarn density:
　　Method of reeled yarn".
主要技术参数：Main Technical Data
　　1、可同时试验纱管 Number of bobbin to tested at the same time: 6
　　2、纱框周长 Circumference of reel YG086C:1000mm +/-1mm
　　 YG086E:54 in +/-16 in (出口专用for export only)
　　3、摇纱横动往复宽度 Transverse width of skein 35mm
　　4、单根摇纱张力范围 Tensile range of single skein 0～100cN
　　5、外形尺寸 Outline size L780*W660*H480mm
