筒管规格

Bobbin spec

6"(170mm)

结构

Layout

双面机，每台（12-96）锭

Double-sided, one-machine has （12-96） spindles

电源

Power Supply

三相380V 50/60HZ/Three phases 380V 50/60HZ

驱动

Transmission

单锭独立交流马达驱动

Every spindle is driven by a AC motor individually

消耗功率

Power Comsumption

0.09千瓦/锭/0.09KW/spindle

成型筒子

Take-up package

圆形柱(0°)/Cylinrical (0°)锥形；4°20, 5°57, 9°15 cone

筒子直径

Package Diameter

最大200和290毫米／Max．200and 290mm

纱线速度范围

Yam speed

300-1000m/min

电子防重叠装置

Electrical wobble frequency anti-patterning function

变频器控制／Control by the lnverter

定长装置

Length counting device

可编程控制器（PLC）集中控制/显示计长

Controlled and displayed by PLC

张力器

Yarn tension and waxer adjusting device

每锭配置旋转自清洁张力器和上腊

Every spindle has a self-cleaning yarn tension and waxer adjusting device

机械清纱装置

Slub-Catcher

每锭配置可微调机械清纱刀

Every spindle has a Mechanical Slub-Catcher

断纱自停装置

Yarn break control device

电子断纱自停

The spindle will stop when the yarn breaks by a yambreak control device

调速装置

Speed Regulation

变频调速/By inverter

筒纱软边横动装置

Anti-hard edge device

机械式/Mechanically/适合松式/suitable soft winder

电子式清纱装置

Electronic Slub-Catcher

可选配/Ordered separately

空气捻接器

Splicer

可选配/Ordered separately

照明系统（带灯）
Lighting system

可选配/Ordered separately

外形尺寸（毫米）

Dimensions

13700(长/length)×1050(宽/width)×1650(高/height)mm
